Safety: Circuit breaker 5A Amber Flashing Light Indicator (Super ActivO in operation) Red Fault Indicator Buzzer Alarm (operation has begun operation has ended) Differential Pressure Regulator (air flow obstructed) Door Interlock (front panel not closed) Dimensions: 50 x 40 x 100 cm, with handle attached 66 x 53 x 94 cm, packed for shipping, handle detached Ozone outlet duct: 4 diameter Weight: 34 kg packed for shipment 40 kg Enclosure: Metal and ABS Wheels: leave no tracks Low EM Noise. With special input code: 72 hours, ozone generation only Control: Digital keyboard Display: LCD, 16 Digits. Cycle time: Minimum 15 minutes, Maximum 48 hours. Ozone output: 12g/h (12,000 mg/h) Operation: Fully Automatic Activation & Deactivation Cycles. 5.2 Technical Specifications: Input Voltage: 230V 50Hz Air Flow-Rate: 450 m³/h. The Super ActivO employs Ecozone s state-of-the-art and patented Singlet Unit which is characterized by relatively high activation rate and enhanced reliability. It features the most advanced technology in the field of odourcontrol and air-treatment.
#Ctivo manual portable#
Technical Specifications 5.1 Description The Super ActivO system is a portable high-duty and rugged system. There are no user serviceable parts inside the Super ActivO removal of back panel by unauthorized personnel will result in voiding the WARRANTY! 4ĥ 3. Prior to removing the grill for maintenance, always disconnect the unit from power. Under no circumstances should the unit be operated with the front panel grill loose or missing. Attempting to bypass the earth or to connect the unit to an un earthed socket is strictly prohibited. AVOID ELECTRICAL SHOCK This unit is supplied with a earthed cable. Place unit in the CENTER of the room DO NOT disconnect cable cord from mains socket before the operation of the system is completed. DO NOT BLOCK inlet/outlet or place foreign objects in their vicinity which may block air flow. This system is equipped with a ventilation inlet and a ventilation outlet. DO NOT enter the treated room during the operation of the system, or before hearing the completion-of-cycle audio alert-signal. When unplugging, never pull the plug by the cord itself. Unplug the system power plug when it is not in use. Should any liquid come into contact with the system, unplug it and have it serviced by qualified personnel before operating it further. Do not expose this equipment to rain or moisture.
#Ctivo manual manual#
EN, EN, EN, EN 5501 EMC, FCC Part 15 Safety of Low Voltage Directive 73/23/EEC as Amended: ENĤ Safety Precautions & Warnings Read this manual carefully before operating the unit. POCS-500 (POCS= Portable Odour Control System) This unit fully complies with CE & FCC rules of EMC regulations. In the second stage, any aftertreatment residual ozone is decomposed into oxygen, so as to leave the treated room well within the regulated levels.
In the first stage the room is enriched with ozone (generated from the air using Ecozone s multipatented technology) at a particularly high rate in order to reach homogeneous conditions and a high concentration level within the shortest possible time. The system incorporates ECOZONE's unique ADA system, a double-stage operating cycle that creates ozone and subsequently removes it, allowing the immediate reoccupation of treated spaces. This robust, computer controlled and automatic system is characterized by high safety standards. General Information Ecozone s Super ActivO is a mobile and easy-to-use deodorizing system for indoor use. Place handle on top panel and fasten 3 hex screws on each side. Lift unit up slightly and then pull out by rolling on its wheels. 3 Declaration of Conformity.4 Safety Precautions & Warnings.4 The Super ActivO control panel and other indicators.5 Technical Specifications 6 Operation 7 Controller settings Activation, Deactivation and Total Operating Time.13 Maintenance and Service Troubleshooting Warranty.19 UNPACKING PLEASE SEE OUR UNPACKING VIDEO PROCEDURE AT: Open top flaps of carton. 1 Super ActivO TM User Manual for Europe 2014 Environmentally activated byĢ User Manual Table of contents Unpacking.2 General Information.
